Follow up EX#9

To speed up the process, you may want to use Claude cowork to run the batch using Python which Claude will make one for you automatically.

1. BJT Diff Pair

Interesting result — the MNA contradicts the React optimizer. Let me sweep mirror mismatch to show what's going on:The MNA disagrees with the optimizer by oo dB. Here's why:

                     analytic (React)       MNA (full nodal solve)
  |Ad|                       1286.7                  1293.4
  |Acm|                   3.50×10⁻⁵               1.70×10⁻³
  CMRR (dB)                   151.30                  117.65
                                              ← 34 dB lower

Root cause: PNP mirror β-error, which the React formula completely omits.

The textbook expression Acm = 1/(2·gm·R_tail) assumes a perfect mirror — gain exactly 1. Real PNP mirrors lose 2/(β+2) of the reference current to base currents. With β_p ≈ 106:

δ_β = 2/(β+2) = 1.84%
Predicted Acm from β-loss: δ·Rout/(2·R_tail) = 1.66×10⁻³
Observed Acm (MNA):                            1.70×10⁻³
→ β-error explains 98.1% of the actual CM gain

The tail-impedance term (3.5×10⁻⁵) is real but it's the floor, not the dominant contributor. The mirror β-error is 48× larger and sets the actual CMRR.

Mirror Is-mismatch sweep confirms the mechanism — there's an asymmetric peak where Is mismatch cancels β-loss:

  ΔIs/Is     CMRR
   −5%      106.5
   −2%      111.5
    0%      117.7   ← matched (β-loss alone)
   +1%      123.8
   +2%      155.7   ← cancellation peak (Δ_Is exactly = δ_β)
   +3%      123.5
   +5%      114.2

That sharp 156 dB peak at +1.84% is real but useless — it's a single bias-trim point. Process variation puts every die somewhere else on the curve.

Monte Carlo with realistic process σ (0.5% Is, 1% β):

  CMRR mean   = 119.4 dB
  CMRR median = 117.5 dB
  CMRR p10    = 112.8 dB
  CMRR p90    = 127.4 dB
  CMRR std    =   7.3 dB

Verdict on the optimizer's CMRR numbers: systematically optimistic by ~33 dB. The 117–120 dB result is in line with what real BJT diff pairs with active loads achieve (LM394: 120 dB typ; MAT02: 124 dB typ — both trimmed). The optimizer's 151 dB was the textbook ceiling for an idealized topology, not what the topology actually delivers.

Two-line fix for the React calcPerf:

const deltaBeta = 2 / (bp + 2);                          // mirror β-loss
const Acm_beta  = deltaBeta * Rout / (2 * RoTail);
const AcmTotal  = Math.hypot(AcmLin, Acm_beta);          // RMS combine
const CMRR      = 20 * Math.log10(AdLin / AcmTotal);

That alone pulls the reported CMRR from 151 to ~118 dB and aligns it with what an MNA — or a real chip — would show.


EX#9 Benchmark IC Design Quality

  課堂練習

Deadline: This Saturday at 23:59

Send all the share links to  me chang212@gmail.com by email with subject EX#9 [your id, your name]


Part 1

Use Claude CoWork or Claude.ai/aistudio to benchmark  BJT Differential Pair

 1. Experiments with 30 seeds


schematic with parameter optimizer


Hint: prompts for CoWork
Prompts for Claude Chat


Part 2

1. Benchmark the three algorithms (GD, NM, A*) and their cascades (one designed by you and the other design by AI )

  • For the five methods, each runs with 10 seeds
  • Tabulate Gain, Pout, PAE, OP1dB, S₁₁ (5 methods = 5 tables, each table with 5 metrics × 10 seeds = 40 cells).
  • Visualize all of your data

Two-stage Cascode Class-AB RF PA Driver targeting 5G n78 (3.5 GHz) in TSMC 28nm RF

Build Sub 6 GHz Power Amplifier Optimizer with Die Synced
shareartifact (Closed-Form)
